Identify your part using this line drawing of the Hydraulic Unit.
Locate a part on the frame.
- UE H-1043-B146 Ball
- UE H-1043-B145 Wiper
- UE H-1043-B144 O-ring
- UE H-1043-B152 Piston Rod
- UE H-1043-B143 Cylinder Cap
- UE H-1043-B142 O-ring
- UE H-1043-B141 U-Cup
- UE H-1043-B147 Pump Piston
- UE H-1043-B148 Spring Cap
- UE H-1043-B149 Spring
- UE H-1043-B150 Wiper
- UE H-1043-B151 U-Cup
- UE H-1043-B117 Spring Pin
- UE H-1043-B118 Handle Axle
- UE H-1043-B126 Copper Washer
- UE H-1043-B127 Plug Bolt
- UE H-1043-BP100 Pump Assembly Complete
- UE H-1043-B140 Pin
- UE H-1043-B119 Screw Plug
- UE H-1043-B120 Copper Washer
- UE H-1043-B121 Spring
- UE H-1193-B122 Spindle Damping Valve
- UE H-1193-B123 Damping Valve Seat
- UE H-1043-B124 Ball
- UE H-1043-B153 Retaining Ring
- UE H-1193-B128 Spring
- UE H-1193-B129 Release Pin
- UE H-1193-B130 O-ring
- UE H-1043-B15 Lube Fitting
- UE H-1043-B131 Sleeve
- UE H-1043-B132 O-ring
- UE H-1043-B135 Lever Plate
- UE H-1043-B134 Nut
- UE H-1043-B133 Set Screw
- UE H-1043-B139 Ball
- UE H-1043-B138 Ball Base
- UE H-1043-B137 Spring
- UE H-1043-B136 Adjustment Screw
- UE H-1043-B3 Bolt
- UE H-1043-B44 Lock Nut
- UE H-1366-B2 Axle
- Steer Wheel Assembly Options
- UE H-1043-B9 Bearing
- UE H-1365-B10 Half Circle Washer
- UE H-1366-B11 Washer
- UE H-1366-B12 Retaining Ring
- UE H-1043-B13 Dust Cover
- UE H-1365-B4 Thrust Bearing
- UE H-1365-B6 Spring Pin
- UE H-1043-B5 Traverse
- UE H-1043-B7 Retaining Ring
- UE H-1043-B102 Roll Pin
- UE H-1043-B101 Blade Spring
- UE H-1043-B104 Roll Pin
- UE H-1043-B105 Roll Pin
- UE H-1043-B106 Roll Pin
- UE H-1043-B107 Control Lever
- UE H-1043-B109 Handle Pin
- UE H-1043-B110 Roll Pin
- UE H-1043-B111 Roller
- UE H-1043-B112 Bushing
- UE H-1043-B114 Handle Bushing
- UE H-1043-B115 Chain, Adjustment Pin & Nut
- UE H-1043-B113A Control Rod Assembly
- UE H-1043-SHC Handle Assembly Complete Inc. 52-64
- UE H-1043-B103 Lever Roller
- UE H-1043-BK100 Seal Kit (Not Shown)
